The ST180S Mobile Stage Trailer is designed to provide a practical and reliable stage platform for outdoor events where mobility, efficient setup and stable operation are essential. Its integrated trailer structure combines transportation, stage flooring, roof support and event functions into one compact system, reducing the need for separate temporary stage structures at the event site.
Once positioned and properly supported, the stage can be deployed to create a functional performance area suitable for live shows, community events, promotional activities, festivals and touring applications. The reinforced supporting structure provides additional stability for repeated setup and outdoor operation, while the integrated solar power system adds greater flexibility when working at locations with limited access to external power.
Depending on the project requirements, the ST180S can also be configured to support lighting, sound systems and other event equipment. Different functional arrangements and customized options are available, allowing the trailer to be adapted to various event environments and operating requirements.
Mobility, structural stability and flexible power support make the ST180S a versatile mobile stage solution for both temporary and touring outdoor events.
| product name | stage trailer | Model | HY-ST180 | Brand | HUAYUAN | |||||||||
| Overall dimension(mm) | 5400×2250×3150 | stage size(mm) | 4970×6000 | Curb weight(tons) | 3200 | |||||||||
| Exterior plate material | Honeycomb composite board | stage area | 29.5-48㎡ | Floor materials | Composite wood floor | |||||||||
| Mesa height(mm) | 1000-1300 | floor loading | 350Kg/㎡ | Lighting truss | Transverse 3 longitudinal 4 | |||||||||
| framework material | steel structure | Set-up | 2×15 minutes | Light truss load bearing | 450 kg / 1 | |||||||||
| Axle number | 2 | axle | 2 tons | Brakes | Electromagnetic brake | |||||||||
| brake system | Removable single lever | Tyre number | 4 | Tire model | 7.00R16 | |||||||||
| Wheelbase(mm) | 1050 | Suspension type | Plate spring | Drag cover | 50# | |||||||||
| specifications | P4 | P5 | P6 | P8 | P10 | |||||||||
| Size (mm) | 3840×1920 | 3840×1920 | 3840×1920 | 3840×1920 | 3840×1920 | |||||||||
| Area (㎡) | 7.37 | 7.37 | 7.37 | 7.37 | 7.37 | |||||||||
| Module Specification (mm) | 320*160 | 320*160 | 192*192 | 320*160 | 320*160 | |||||||||
| Screen brightness（cd/m2） | ≥6000 | ≥6000 | ≥5000 | ≥5000 | ≥5000 | |||||||||
| Working voltage（V） | 5 | 5 | 5 | 5 | 5 | |||||||||
| Refresh rate（Hz) | ≥1920 | ≥1920 | ≥1920 | ≥1920 | ≥1920 | |||||||||
| Service life（hours） | ≥50000 | ≥50000 | ≥10000 | ≥50000 | ≥50000 | |||||||||
