| product name | mobile stage truck | Model | HY-T315 | Brand | HUAYUAN | |||||||||
| Overall dimension(mm) | 7000x2300x3400 | stage size(mm) | 7700x9380 | weight | 8500kg | |||||||||
| Exterior plate material | Aluminum Flat Plate | stage area | 64.5㎡ | Floor materials | 18mm custom birch core waterproof anti-slip stage board | |||||||||
| Mesa height(mm) | 1150 | floor loading | 500Kg/㎡ | Lighting truss | 11 in total | |||||||||
| framework material | Aluminum Alloy | Set-up | 2×1.5 hours | Light truss load bearing | 700 kg / 1 | |||||||||
| brand | JAC | Chassis models | HFC1251P2K3D54S1V | Emission standards | Ⅱ、Ⅲ、Ⅳ、Ⅴ、Ⅵ | |||||||||
| Fuel | diesel | Engine type | WP6.180E50 | Power （kw） | 179 | |||||||||
| Displacement (ml) | 6600 | Tire size | 10.00R20 | Axial distance (mm) | 1900+5400 | |||||||||
| specifications | P4 | P5 | P6 | P8 | P10 | |||||||||
| Size (mm) | 6400×3200 | 6400×3200 | 6336×3264 | 6400×3200 | 6400×3200 | |||||||||
| Area (㎡) | 20.48 | 20.48 | 20.68 | 20.48 | 20.48 | |||||||||
| Module Specification (mm) | 320*160 | 320*160 | 192*192 | 320*160 | 320*160 | |||||||||
| Screen brightness（cd/m2） | ≥6000 | ≥6000 | ≥5000 | ≥5000 | ≥5000 | |||||||||
| Working voltage（V） | 5 | 5 | 5 | 5 | 5 | |||||||||
| Refresh rate（Hz) | ≥1920 | ≥1920 | ≥1920 | ≥1920 | ≥1920 | |||||||||
| Service life（hours） | ≥50000 | ≥50000 | ≥10000 | ≥50000 | ≥50000 | |||||||||
