HY-LT5 LED BILLBOARD TRAILER

The LT5 is a mobile LED display trailer designed for outdoor events, promotional campaigns and public information. Its 2880 × 1600 mm LED screen provides a display area of approximately 4.6 sqm, offering more viewing space than the smaller LT3 while retaining a relatively compact single-axle trailer structure. The screen is hydraulically raised by 1000 mm and can be manually rotated through 360° after deployment. With an overall size of 3500 × 1600 × 2645 mm, the LT5 can be towed by a suitable pickup or SUV and moved between different event or advertising locations.

LED SCREEN SPECIFICATIONS: P5（optional P3/P4/P5/P6）

LED SCREEN SIZE: 2880 × 1600 mm

LED SCREEN AREA: 4.6㎡

SERVICE LIFE（HOURS): ≥100000

OVERALL DIMENSION: 3.5M×1.6M×2.645M

WEIGHT: 1450KG

Lift/rotate: 1000mm/Manual 360°

TOWING: PICKUP/SUV

REQUEST A QUOTE

DOWNLOAD

Share With:

LT5 mobile LED display trailer connected to a towing vehicle

Rear view of LT5 outdoor event LED trailer with screen raised

LT5 portable video screen trailer during outdoor display testing

Side view of LT5 4.6 sqm LED advertising trailer

Mobile LED screen trailer with stabilizing legs deployed

LT5 outdoor digital display trailer in raised working position

Single axle LED trailer displaying promotional video outdoors

Product description

The LT5 is deployed by parking the trailer on firm, level ground and adjusting the mechanical support legs. The hydraulic system raises the LED screen by 1000 mm, after which the display can be manually rotated to face the intended viewing area.

The 2880 × 1600 mm screen provides a display area of approximately 4.6 sqm. P3, P4, P5 and P6 pixel pitches are available, allowing the LED configuration to be selected according to viewing distance, content type and operating location.

The trailer measures 3500 × 1600 × 2645 mm and weighs approximately 1450 kg. Its single-axle structure provides a larger display than the LT3 without moving into the size and transport requirements of HUAYUAN’s medium and large LED trailers.

Power can be supplied through an external electrical connection or a compatible generator. The LED screen, control equipment, braking system and trailer coupler can be configured according to the intended application, towing vehicle and destination-market requirements.

Technical Parameters

VEHICLE PARAMETERS

product name

LED billboard trailer

Model

HY-LT5

Brand

HUAYUAN

Overall dimension(mm)

3500×1600×2600M

Lift/rotate

1000mm/Manual 360°

weight(tons)

1450KG

Lifting way

hydraulic system

stable system

Semi-automatic screw type

power distribution

mains supply /generator

framework material

steel structure

Platform height (mm)

700

Screen lift height

TRAILER PARAMETERS

TOWING

PICKUP/SUV

Tyre number

Brakes

electric brake (12v/24v)

Suspension type

Plate spring

Tire model

LT265/70R16

Minimum turning diameter(mm)

≤18000

Single wheel bearing(kg)

560

Axle number

Traction pin

50#

LED SCREEN PARAMETERS

specifications	P4	P5	P8	P10
Size (mm)	2560×1600	2560×1600	2560×1600	2560×1600
Area (㎡)	4.09	4.09	4.09	4.09
Module Specification (mm)	320*160	320*160	320*160	320*160
Screen brightness（cd/m2）	≥6000	≥6000	≥5000	≥5000
Working voltage（V）	5	5	5	5
Refresh rate（Hz)	≥1920	≥1920	≥1920	≥1920
Service life（hours）	≥50000	≥50000	≥50000	≥50000
